Calore C&A Chama Modular Cristal 69 Wood Fireplace
Calore C&A Chama Modular Cristal 69 Wood Fireplace
Description
Description
The C&A Chama Modular Cristal 69 Wood Fireplace is a versatile and stylish addition to any home. With its modern, modular design, this fireplace adds both function and beauty to any room. With a maximum heat output of 13.7kW, it has the power to heat up to 250 m3. The fireplace is also highly efficient, with a nominal efficiency of 83%. It features an ashtray for easy cleaning and is available in various modular options, including no base, with a four-feet base, with an extended bench, with a pedestal, with a wall suspension kit, or with a wood log holder. Optional accessories like a ventilation kit are also available.
Bring warmth and comfort to your home with the C&A Chama Modular Cristal 69.
| Firebox Material | Steel |
| Internal Firebox Material | Steel & vermiculite |
| Dimensions (mm) | H552 x W700 x D435 |
| Heating Capacity (Cubic meters) | 415 |
| Nom to Max Output Range (kW) | 8 – 13,7 |
| Nominal Efficiency (%) | 80 |
| Nominal Fuel Consumption (kg/h) | 2 |
| Convection Type | Natural – Optional Fan Kit |
| Distance from flammable materials (mm) | 1000 |
| Product Weight (kg) | 115 |
| Warranty – Structural | 5 Years |
| Warranty – Electrical/Mechanical | 2 Years |
Price excludes installation, flues and consumables.
| Ash Tray |
Yes |
|---|---|
| Brand |
C&A Chama |
| Clean Glass Airflow |
Yes |
| Convection Type |
Natural |
| Finish |
Steel |
| Flue Diameter (mm) |
180 |
| Flue Exit |
Top |
| Nominal Efficiency (%) |
83 |
| Nominal Output (Kw) |
8 |
| Kw Output |
8-13.7 |
| Smart Class |
Traditional Wood Fireplaces |
| Unit Dimensions (WxDxH) |
700 x 435 x 552 |
| Weight (Kg) |
115 |
| Modular options |
Firebox Only, With 4 Feet Base, With Extended Bench, With Pedestal, With Wall Suspension Kit, With Wood Log Holder |
| Fuel |
Wood Burning |
| Optional Accessories |
Ventilation Kit |
DATA SHEET:
To download the Calore C&A Chama Modular Cristal 69 Wood Fireplace Data Sheet click here.
